pre-owned fundex f2200
The used FUNDEX F2200 is the basic model range of Fundex Equipment multifunctional foundation rigs. The F2200 is used for a variety of drilling methods such as soil displacement drilling and CFA drilling.
Specifications of the USED FUNDEX F2200
| Rig | FUNDEX F2200 |
|---|---|
| Serial number | 08.2200.01 |
| Year of manufacture | 2008 |
| Engine power | 330 kW, Deutz V6 |
| Running hours | 12.560 |
| Pull-up winch | 15 ton = 60 ton pull-up force |
| Pull-down winch | 10 ton = 20 ton pull-down force |
| Auxiliary winch | 3 ton |
| Man lift winch | 0.9 ton (till 15 mtr leader length) |
| Standard leader length | 25 mtr |
| Stroke sliding table | 1.750 mm |
| Transport width | 3.5 mtr |
| Transport heigth | 3.5 mtr |
| Transport length (incl. leader head) | 18.15 mtr |
| Transport weight incl. FDE25 rotary head and 10 ton counter weight | 64.5 ton |
| Transport weight excl. FDE25 rotary head and incl. 10 ton counter weight | 58 ton |
| Transport weight incl. FDE25 rotary head and excl. 10 ton counter weight | 54.5 ton |
| Rotary head | FDE25 (08.25.02) |
| Year of manufacture | 2008 |
| 1st gear (max. torque) | 250 kNm (12 rpm) |
| 2nd gear | 180 kNm (17 rpm) |
| 3rd gear | 100 kNm (30 rpm) |
| Including | Automatic greasing system |
| 4 emergency stops around the machine + 1 in the cabin |
ADVANTAGES OF THE USED FUNDEX F2200
- the leader can be folded down
- it is often not necessary to dismantle the rotary head or hammer while transporting
- the strong tubular leader is suitable for a torque of 250kNm over the entire leader length
- standard leader length is 25 meters
