pre-owned fundex f2800
The used FUNDEX F2800 is a medium-sized and powerful model in the range of Fundex Equipment multifunctional foundation rigs. The F2800 can be used for various drilling and pile driving techniques such as soil mixing, sheet pile push pull system and vibratory hammers.
Rental on request
Completely overhauled in 2021
Specifications of the USED FUNDEX F2800
| Rig | FUNDEX F2800 |
|---|---|
| Serial number | 07.2800.06 |
| Year of manufacture | 2007 |
| Engine power | 440 kW Deutz, V8 BF8M 1015, Tier II |
| Running hours engine (new) | 72 |
| Running hours machine | 7.078 |
| Pull-up winch | 10 ton = 80 ton pull-up force |
| Pull-down winch | 10 ton = 40 ton pull-down force |
| Top jib winch | 5 ton |
| Auxiliary winch | 1.5 ton |
| Man lift winch | 0.9 ton |
| Standard leader length | 28 mtr |
| Max. leader length | 31 mtr |
| Stroke sliding table | 1.200 mm |
| Undercarriage width | 3.500 - 4.900 mm |
| Track width | 900 mm, 3-ribs |
| Transport width | 3.5 mtr |
| Transport heigth | 3.5 mtr |
| Transport length (incl. leader head) | 20.5 mtr |
| Transport weight rig | 63 / 68 ton |
| Rotary head | FDE45 (07.46.52SE) |
| Year of manufacture | 2007 |
| Weight | 7.5 ton |
| 1st gear (max. torque) | 450 kNm (7 rpm) |
| 2nd gear | 225 kNm (14 rpm) |
| Including | Data acquisition system |
ADVANTAGES OF THE USED FUNDEX F2800
- the extension pieces of the leader are fed in from the bottom, which is beneficial in limited spaces
- high stability thanks to both front and rear supports as well as a low centre of gravity
- 440 kW powerful engine
- torque of 500 kNm along the entire leader length
- man lift along the entire leader length
