Specifications of the USED FUNDEX F2800

Rig FUNDEX F2800
Serial number 11.2800.19
Year of manufacture 2011
Engine power 440 kW Deutz, V8 Tier 3
Running hours 10.400
Pull-up winch 10 ton = 80 ton pull-up force
Pull-down winch 10 ton = 40 ton pull-down force
Top jib winch 5 ton
Auxiliary winch 1.5 ton
Man lift winch 0.9 ton
Standard leader length 28 mtr
Max. leader length 31 mtr
Stroke sliding table 1.200 mm
Undercarriage width 3.500 - 4.900 mm
Track width 900 mm, 3-ribs
Transport width 3.5 mtr
Transport heigth 3.5 mtr
Transport length (incl. leader head) 20.5 mtr
Transport weight rig 63 / 68 ton
Rotary head FDE45HS (12.18.45HS)
Year of manufacture 2012
Weight 8.5 ton
1st gear (max. torque) 470 kNm (7 rpm)
2nd gear 300 kNm (12 rpm)
3rd gear 180 kNm (19 - 21 rpm)
Including Data acquisition system

ADVANTAGES OF THE USED FUNDEX F2800

  • the extension pieces of the leader are fed in from the bottom, which is beneficial in limited spaces
  • high stability thanks to both front and rear supports as well as a low centre of gravity
  • 440 kW powerful engine
  • torque of 500 kNm along the entire leader length
  • man lift along the entire leader length

applications suitable for the used FUNDEX F2800
